Current transformer TEMBREAK
The TEMBREAK has been designed for TEMBREAK circuit breaker.
![](/fileadmin/_processed_/f/a/csm_TEMBREAKT2_product_image_Produktbild_e86a5a9b39.jpg)
- Current transformer for compact circuit-breakers
- Three-phase design
- Moulded in Polyurethane
- Minimum space requirement
- Easy installation
- Standard: IEC/EN 61869-2
- Official calibration possible
Specifications and Downloads
Technical Specifications
TEMBREAK T2 3-phased
![](/fileadmin/_processed_/d/8/csm_TEMBREAKT2_3-phased_drawing_3-phasig_Massbild_993086edfd.png)
TEMBREAK T2 4-phased
![](/fileadmin/_processed_/e/0/csm_TEMBREAKT2_4-phased_drawing_4-phasig_Massbild_bc14e40928.png)
TEMBREAK T3 3-phased
![](/fileadmin/_processed_/b/0/csm_TEMBREAKT3_3-phased_drawing_3-phasig_Massbild_6b67e5fbd8.png)
TEMBREAK T3 4-phased
![](/fileadmin/_processed_/1/4/csm_TEMBREAKT3_4-phased_drawing_4-phasig_Massbild_5af8b98293.png)
TEMBREAK T5 3-phased
![](/fileadmin/_processed_/8/a/csm_TEMBREAKT5_3-phased_drawing_3-phasig_Massbild_138e7510e8.png)
TEMBREAK T5 4-phased
![](/fileadmin/_processed_/f/1/csm_TEMBREAKT5_4-phased_drawing_4-phasig_Massbild_8daf7d6c45.png)
Technical data
Highest operating voltage | 0.72 kV |
Test voltage | 3.0 kV |
Frequency | 50/60 Hz |
Secondary current | 5 or 1 A |
Continuous thermal current | 105 % Ipr |
Short-time thermal current | 60 Ipr 1s |
